There are more elements to a door than one might think, and this video and article will go over an interior door’s anatomy.
Door Casing vs Door Jamb vs Door Frame
The first part is the casing, and is not actually a part of the door, but is a piece that is installed over the sheetrock and door frame that goes around the door. When you open the door, you go from the door casing to the door jamb. Together, two vertical door jambs and one horizontal door jamb make up the door frame. A door frame is usually 4-9/16” wide, but can also be 6-9/16” wide.
Door Casing and Door Frame
Door Stops
An applied stop keeps your door from swinging through and going forward. There are two types of stops: a bullnose or flat stop, and a colonial stop. The function is the same, but the profiles of these stop mouldings are different, as shown below.
Door Stops
Door Hinges
On the other side of the door panel are the hinges, and standard interior doors typically have three. You can choose either square or radius hinges, and they each come in multiple finishes. Most people like their hinges to match the door’s lockset, or hardware that makes up the latching mechanism on a door (handles, locks, latches, strike plates, etc.).
Door Hinges
Bores
The holes in a door are called bores, and there will be two on the door panel – one going straight through the front of the door panel for the door knob and one on the side of the door panel for the door catch, or latch. There will be another bore on the door jamb for the door strike. All together, these bore holes accommodate a lockset.
Bores
Pre-Hung Doors
If you need an entirely new door system, you can order a pre-hung door, which consists of the door frame without the casing, the door panel, the applied stops, and door panel pre-bored. While we’ve been focusing on single interior doors, there are also double interior doors, which can also be ordered pre-hung.
Single Interior Door vs Double Interior Door
Ring’s End carries a large variety of interior doors and all of our full-service locations have in-store displays so you can choose the right doors for your home. Come visit us and we can help you order exactly what you need!
