Simpson Strong-Tie LUS Light-Capacity U-Shaped Hanger for Double 2 x 6, ZMAX®
The LUS is an easy-to-install, economical hanger designed for common lumber sizes. This widely used hanger features double-shear nailing that distributes the load through two points on each joist nail for greater strength. This allows for fewer nails, faster installation and the use of all common nails for the same connection. Dimensions: Width 3-1/8 in. Height 4-7/8 in. Depth (B) 2 in.
$4.10
each
- Cannot be modified
- Works for a wide range of applications
- Features speed prongs used to temporarily position and secure the connector for easier and faster installation
- LUS-series hangers are tested, load rated and code compliant
| Type | Face-Mount Hangers |
|---|---|
| Size | 2 x 6 |
| Gauge | 18 ga. |
| Style | Double |
| Brand | Simpson Strong-Tie |
| Finish | ZMAX® |
| Material | Steel |
| Manufacturer Code | LUS26-2Z |
"Use all specified fasteners; see General Notes
Joists sloped up to 1/4:12 achieve table loads
When nailing into solid sawn carrying member's end grain, the allowable load is adjusted by a factor of 0.77"
